M8 Cable Assembly

Name: M8 Cable Assembly
Brand: relaxadulttoys
SKU: DQ-004
Availability: InStock

can provide high quality straight and right angle m8 3 pin male cable for actuator and sensor.
Product series: M8 Cable Assembly
Wire gauge: 20-26 AWG
Connector Gender: Female
Waterproof Rating: IP67
Contact number: 3 Pin
Plug Guide: Right

0.0 (0 Reviews)

0 Sold

$0.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

M8 molded cable connector (plug) product, the connector parts and the cable have been injection-molded together before leaving the factory. Our common wire material is PUR or PVC outer jacket material cable, and the internal core wire is required according to the terminal application of the product. We commonly use PVC, SR-PVC, PP, PE and other materials for selection. The matching M8 board end connectors (sockets) include electronic wire welding type and PCB board pin type. The M8 board end welding type can be welded electronic wire and resin potting package according to customer's reservation requirements.

Product series: M8 Connector Cable	Connector Gender: Male
Industry standard: IEC 61076-2-104	Connector core number: 3P
Plug Guide: Right Angle	Terminal Material: Copper
Waterproof grade: IP67	Wiring method: welding wire
Wire gauge: 20-28AWG	Connection method: threaded connection
Connector rubber core: PA66	Injection material: TPU
Rated current: 4A	Connector conductor: copper gold plated
Rated voltage: 30V	Insulation resistance: ≥100mΩ
Sealing method: O type sealing ring	Conductor resistance: ≤5mΩ
Applicable temperature: -20°- +80°	Wire cover: PVC/PUR

●Sensors, actuators, encoders, motors	●Industrial grating light curtains
●Factory automation process control	●Equipment battery, semiconductor
●Package label printing equipment	●Fieldbus: DeviceNet, CANopen, etc.
●Industrial instruments and equipment	●NMEA 2000 ship electronics, rail transit
●EMS circuit board assembly	●LED outdoor display, outdoor LED lighting
